Posted in Uncategorized on 9 July 2022 by Craig Latta
a canvas that paints HTML
SqueakJS not only enables us to run to Squeak in web browsers, it also features a bidirectional JavaScript bridge that lets us invoke JS functions from Smalltalk and evaluate Smalltalk closures from JS. This lets us use Smalltalk closures as functions for JS callbacks and promises, and manipulate ES6 classes and modules. In particular, we can make full use of the JS event system underlying the web browsers’ DOM-based user interfaces.
The Caffeine system, built with SqueakJS, makes heavy use of these facilities, bringing the Smalltalk livecoding experience to web development. I’ve used it to provide a web-native version of the Smalltalk IDE itself. Rather than make a new subclass of Squeak’s ToolBuilder, I made a new Morphic canvas. When morphs draw themselves on it, the canvas creates and connects appropriate HTML DOM objects into the shadow DOM of a dynamically-created Web Component. It’s rather like a 3D printer. With tools that can mingle with the rest of the content on a webpage, I’d like to create better user interfaces for editing, debugging, and storing webpages.
livecoding Web Components
a class browser duplicated live in HTML
Caffeine augments the JSObjectProxy class from SqueakJS with a JSObject class, adding Smalltalk behavior and documentation to proxied JS objects. A further subclass, JSClass, proxies ES6 classes, and its subclass WebComponent can create a JS class and register it as a web component. Finally, the web component subclass HTMLWorld provides the behavior we’re discussing here.
HTMLWorld supports much of the Morphic drawing and canvas behavior, such as drawing rectangles, images, and strings. For some morphs, a world delegates to an instance of class in the HTMLMorph hierarchy. These classes have knowledge about specific widgets such as buttons, lists, and text editors, for both Morphic and HTML. Since most Morphic user interfaces are built from a small set of these widgets, an HTMLWorld is able to create HTML equivalents without any UI-specific knowledge.
Leveraging this, one can open the HTML equivalent for any morph from within the morph, by evaluating:
thisContext openInHTML
The receiving context can search the sender chain for the morph scope in which the expression was evaluated, and ask it to draw itself on an HTMLWorld. One may also set the system so that any time a morph is opened from a morph scope which already has an open HTML equivalent, another HTML equivalent is opened in turn for the later morph. This lets us make a smooth transition from the traditional Morphic IDE to an HTML counterpart. Ultimately, we can simply make the main Squeak HTML canvas transparent, using it when needed but using HTML UIs for most work.
renovating web browser UIs
With the ability to livecode user interfaces that can manipulate other DOM content around them, we can develop more flexible alternatives to existing web browser UIs. The next one I’d like to tackle is the Chrome Devtools UI. Currently, it takes the form of a set of panels that run alongside the subject page, and is very limited in its use of graphics and persistence. For example, at a given moment one may look at a page’s elements, or a debugger, but not both. One inspects an element by evaluating console expressions, or with a limited properties editor that is cumbersome to use with multiple elements simultaneously.
With the web-component-based UIs we can make with Caffeine, we can build open-ended UIs to the DevTools facilities, with multiple open windows. We can respond to events from the code being debugged, and from the debugger. We can bring some of the process manipulation experience from the Smalltalk debugger to debugging JavaScript.
What will you build?
This code is live now. If you have any questions, please let me know!
In a traditional EBNF grammar, production rules describe all the allowed relationships between a language’s terminal symbols. By expressing them as live objects with behavior, they can parse and compile as well. They form a definitive reference network in which to record parsed terminals, making them ideally suited as parse trees. Individual rules also function as search terms in other rules which use them. Epigram is a framework for doing this. Let’s explore these features with an example.
Each diagram shows a path going through one or more symbols. An EBNF production rule, or grammar symbol, is indicated by the name of the rule in a box. A terminal symbol is indicated by a circle with the symbol inside. An alternation is indicated by a path’s divergence through multiple symbols, converging afterward. A compound rule is indicated by a path going directly through multiple symbols. A repetition is indicated by a loop through a sequence of symbols, representing one or more occurrences of that sequence. EBNF also supports the option, which is no or one occurrence of a symbol, and the difference, which matches one rule but not another. These kinds of rules are sufficient for the Smalltalk grammar. There are other grammars, like XML, that extend BNF further, but we won’t discuss them here.
production rules as code
We can express these diagrams as code. For a terminal symbol, we can use a literal string. For an alternation, we can use a “|” (“or”) operator. For a compound rule, we can use a “||” (“then”) operator (after changing the Smalltalk compiler so that it doesn’t confuse “||” with “|”). For repetitions and options, we can use the unary messages “repetition” and “option”. We can store entire production rules as shared variables (pool variables in Squeak).
Digit is an instance of class Alternation, and can be a variable in a SmalltalkProductionRules pool. We can write the second diagram as:
Digits := Digit repetition.
Digits is an instance of class Repetition. A rule which uses a compound rule is:
SymbolConstant := '#' || Symbol.
We can write each rule in this way, culminating with Method.
parsing
Once we’ve created all the rules for our grammar, we can ask the topmost rule, Method, to parse the source code of a method. To parse, a rule creates a stream on the proposed content, and attempts to accept the next character in the stream until the stream is empty. For example, a terminal symbol for ‘3’ will accept the next character if it is $3.
A symbol which consists of other symbols will delegate parsing to those symbols. An alternation between the terminal symbols for ‘3’ and ‘4’ will accept the next character if it is $3 or $4, but it decides this by delegating the parse to each of those symbols, and noting which of them was able to accept the next character. A symbol’s parse succeeds if it is able to accept enough characters to match every character in its string, if it’s a terminal symbol, or a sufficient set of subsymbols, if it’s a compound rule, alternation or repetition.
If a symbol doesn’t succeed, it fails and resets the stream’s position as it was before parsing began. Control is returned to the delegating symbol. This is called backtracking. If the overall parse backtracks all the way to the topmost rule without having emptied the stream, and the next character is unacceptable, then the entire parse fails and the content is ungrammatical. Having reached this point, however, we have information about which rules failed and how far the parse got in the stream. This is useful information to present to the user, with an exception.
The complexity of a grammar can make backtracking very expensive in time; reducing this cost is the main challenge in Epigram development currently. Informed choices of alternation orders in a grammar (as with a parsing expression grammar) and primitives (described below) yield dramatic performance increases.
compilation
If a parse is successful. We are left with a graph of successful production rules, each with a record of the characters it accepted, and its successful constituent symbols. We can use this graph as we would have used a traditional parse tree. Compilers can use the parse graph to create objects representing the source content in a useful structure. For example, we can create a CompiledMethod of Smalltalk virtual machine instructions, embodying the behavior specified by the source code.
For example, if our source code were:
The successful rules in our parse, in chronological order, would be:
Letter ($a)
Letter ($d)
Letter ($d) — further Letter successes are elided.
Identifier (‘add’)
UnarySelector (‘add’)
MessagePattern (‘add’)
SpecialCharacter (carriage return)
SpecialCharacter (tab)
Comment (‘”Add two numbers and answer the result.”‘)
Digit ($3)
Number (‘3’)
Literal (‘3’)
SpecialCharacter ($+)
BinarySelector (‘+’)
Literal (‘4’)
BinaryExpression (‘3 + 4’)
MessageExpression (‘3 + 4’)
Expression (‘3 + 4’)
Statements (‘3 + 4’)
Method (‘add “…” ^3 + 4’)
To get the intended method selector (#add), a compiler holding this parse history can simply ask the Method rule for its MessagePattern. The compiler can also ask the Expression to generate the Smalltalk stack machine instructions that carry it out.
searching
Since MessagePattern is a well-known shared variable in the SmalltalkProductionRules pool, the compiler can use it as a search term in queries to Method:
selector := (Method at: MessagePattern) terminals
Using production rules as search terms is a very useful way of navigating the grammatical structure of the parse tree, allowing the compiler writer to apply their knowledge of the grammar. Rather than focusing on how parsing works, or how to manipulate a parse tree which is separate from the grammar, one may express compilation entirely with the grammar’s rules.
performance optimization: primitives
It’s very convenient and clear to express a grammar as EBNF rules, but it can lead to alternations between many options, with expensive parsing behavior. Since the grammar keeps a complete history of the accepted rules for a parse, we can easily see which rules are most popular and consume the most time. For these rules, we can specify Smalltalk code equivalent to their parsing work, providing primitives. For XML, which has frequently-used alternations between thousands of Unicode characters, primitives provide speedups of 200 times or more.
enforcing constraints
Some grammars specify additional constraints on parsed content. For example, the HTML grammar requires an element’s opening and closing tags to match. Epigram supports adding constraints to production rules, in the form of block closures which must evaluate to true after parsing has taken place.
resolving ambiguities
Some grammars include points of intentional ambiguity. In Smalltalk, for example, there’s a grammatical ambiguity between chains of unary and binary messages. Epigram supports noting ambiguities, and resolving them through constraints. In the Smalltalk example, the ambiguity is resolved through constraint considering the scope in which parsing occurs. Which variable names are currently bound, and which unary and binary messages are actually defined, lead to a single interpretation.
decompilation
Writing a Smalltalk decompiler with reified production rules is also easier. The rule for a method declaration can dispatch decompilation for each bytecode to the corresponding instruction class, resulting in a set of equivalent instruction instances. An instruction which pops the virtual machine stack corresponds to a Smalltalk statement, and it can construct a structure of production rules equivalent to that statement, as if created from a parse. The rule structure can answer terminal symbols which are the equivalent source code. I’m writing an extended example of this decompilation process, as an Observable active essay with a live Caffeine session embedded inside it.
special thanks
Special thanks to Chris Thorgrimsson and Lam Research, for supporting this open-source work through commercial use cases.
Squeak turns 25 on Friday, 24 September 2021. Let’s celebrate! We’ll begin with an informal online gathering, at https://8×8.vc/3plus4/cast. It will start at 11am pacific time (18.00 UTC), and last all weekend, so that folks from all timezones may attend. To increase the chance of crossing paths, let’s aim for peaks at each noon and midnight UTC. We’ll also use https://squeak.slack.com as a text backchannel, starting now.
Proceed for Truth!
things that may happen…
12:01 am Sunday UTC: a virtual tour of Jecel Assumpção Jr’s workshop, filled with exotic hardware delights…
Send a direct message if you’d like to schedule something…
I’ve written a Caffeine class which, in real time, takes detected pitches from a melody and chords, and sends re-voiced versions of the chords to a harmonizer, which renders them using shifted copies of the melody. It’s an example of an aggregate audio plugin, which builds a new feature from other plugins running in Ableton Live.
re-creating a classic
Way way back in 1991, before the Auto-Tune algorithm popularized in 1998, a Canadian company called IVL Technologies developed a hardware harmonizer, the Vocalist VHM5. It generated five-part vocal harmonies, live from sung melodies and chords played via MIDI. It had a simple but effective model of vocal formants, which enabled it to shift the pitch of a sung note to natural-sounding new pitches, including correcting the pitch of the sung note. It also had very fast pitch detection.
My favorite feature, though, was how it combined those features when voicing chords. In what was called “vocoder mode”, it would adjust the pitches of incoming MIDI chords to be as close as possible to the current pitch of a sung melody, or closed voicing. If the melody moved more than half an octave away from a chord voice, the rendered chord voice would adjust by some number of octaves up or down, so as to be within half an octave of the melody. With kinetic melodies and dense chords, this becomes a simple but compelling voice-leading technique. It’s even more compelling when the voices are spatialized in a stereo or 3D audio field, with reverb, reflections, and other post-processing.
It’s also computationally inexpensive. The IVL pitch-detection and shifting algorithms were straightforward for off-the-shelf digital signal processing chips to perform, and the Auto-Tune algorithm is orders of magnitude cheaper. One of the audio plugins I use in the Ableton Live audio environment, Harmony Engine by Antares, implements Auto-Tune’s pitch shifting. Another, MIDI Guitar by Jam Origin, does polyphonic pitch detection. With these plugins, I have all the live MIDI information necessary to implement closed re-voicing, and the pitch shifting for rendering it. I suppose I would call this “automated closed-voice harmonization”.
implementation
Caffeine runs in a web browser, which, along with Live, has access to all the MIDI interfaces provided by the host operating system. Using the WebMIDI API, I can receive and schedule MIDI events in Smalltalk, exchanging music information with Live and its plugins. With MIDI as one possible transport layer, I’ve developed a Smalltalk model of music events based upon sequences and simultaneities. One kind of simultaneity is the chord, a collection of notes sounded at the same time. In my implementation, a chord performs its own re-voicing, while also taking care to send a minimum of MIDI messages to Live. For example, only the notes which were adjusted in response to a melodic change are rescheduled. The other notes simply remain on, requiring no sent messages. Caffeine also knows how many pitch-shifted copies of the melody can be created by the pitch-shifting plugin, and culls the least-recently-activated voices from chords, to remain within that number.
All told, I now have a perfect re-creation of the original Vocalist closed-voicing sound, enhanced by all the audio post-processing that Live can do.
the setup
a GK-3 hex pickup through a breakout box
Back in the day, I played chords to the VHM5 from an exotic MIDI electric guitar controller, the Zeta Mirror 6. This guitar has a hex (six-channel) pickup, and can send a separate data stream for each string. While I still have that guitar, I also have a Roland GK-3 hex pickup, which is still in production and can be moved between guitars without modifying them. Another thing I like about hex pickups is having access to the original analog signal for each string. These days I run the GK-3 through a SynQuaNon breakout module, which makes the signals available at modular levels. The main benefit of this is that I can connect the analog signals directly to my audio interface, without software drivers that may become unsupported. I have a USB GK-3 interface, but the manufacturer never updated the original 32-bit driver for it.
Contemporary computers can do polyphonic pitch detection on any audio stream, without the use of special controller hardware. While the resulting MIDI stream uses only a single channel, with no distinction between strings, it’s very convenient. The Jam Origin plugin is my favorite way to produce a polyphonic chord stream from audio.
the ROLI Lightpad
My favorite new controller for generating multi-channel chord streams is the ROLI Lightpad. It’s a MIDI Polyphonic Expression (MPE) device, using an entire 16-channel MIDI port for each instrument, and a separate MIDI channel for each note. This enables very expressive use of MIDI channel messages for representing the way a note changes after it starts. The Lightpad sends messages that track the velocity with which each finger strikes the surface, how it moves in X, Y, and Z while on the surface, and the velocity with which it leaves the surface. The surface is also a display; I use it as a five-by-five grid, which presents musical intervals in a way I find much more accessible than that of a traditional piano keyboard. There are several MPE instruments that use this grid, including the Linnstrument and the GeoShred iPad app. The Lightpad is also very portable, and modular; many of them can be connected together magnetically.
The main advantage of using MPE for vocal harmonization is associating various audio processing state with each chord voice’s separate channel. For example, the bass voice of a chord progression can have its own spatialization and equalization settings.
My chord signal path starts with an instrument, a hex or normal guitar or Lightpad. Audio and MIDI data goes from the instrument, through a host operating system MIDI interface, through Live where I can detect pitches and record, through another MIDI interface to Caffeine in a web browser, then back to Live and the pitch-shifting plugin. My melody signal path starts with a vocal performance using a microphone, through Live and pitch detection, then through pitch shifting as controlled by the chords.
Let’s Play!
Between this vocal harmonization, control of the Ableton Live API, and the Beatshifting protocol, there is great potential for communal livecoded music performance. If you’re a livecoder interested in music, I’d love to hear from you!
Livecoding access can tame the complexity of Ableton Live.
I’ve written a proxy system to communicate with Ableton Live from Caffeine, for interactive music composition and performance. Live includes Max for Live (M4L), an embedded version of the Max media programming system. M4L has, in turn, access to both Node.JS, a server-side JavaScript engine embedded as a separate process, and to an internal JS engine extension of its own object system. Caffeine can connect to Node.JS through a websocket, Node.JS can send messages to Max, Max can call user-written JS functions, and those JS functions can invoke the Live Object Model, an API for manipulating Live. This stack of APIs also supports returning results back over the websocket, and for establishing callbacks.
getting connected
Caffeine creates a websocket connection to a server running in M4L’s Node.JS, using the JS WebSocket function provided by the web browser. A Caffeine object can use this connection to send a JSON string describing a Live function it would like to invoke. Node.JS passes the JSON string to Max, through an output of a Max object in a Max program, or patcher:
connecting the Node.JS server with JS Live API function invocation
Max is a visual dataflow system, in which objects inputs and outputs are connected, and their functions are run by a real-time scheduler. There are two special objects in the patcher above. The first is node.script, which controls the operation of a Node.JS script. It’s running the Node.JS script “caffeine-server.js”, which creates a websocket server. That script has access to a Max API, which it uses to send data through the output of the node.script object.
The second special object is js, which runs “caffeine-max.js”. That script parses the JSON function invocation request sent by Caffeine, invokes the desired Live API function, and sends the result back to Caffeine through the Node.JS server.
proxying
With this infrastructure in place, we can create a proxy object system in Caffeine. In class Live, we can write a method which invokes Live functions:
invoking a Live function from Caffeine
This method uses a SharedQueue for each remote message sent; the JS bridge callback process delivers results to them. This lets us nest remote message sends among multiple processes. The JSON data identifies the function and argument of the invocation, the identifier of receiving Live object, and the desired Smalltalk class of the result.
The LiveObject proxy class can use this invoking function from its doesNotUnderstand method:
forwarding a message from a proxy
Now that we have message forwarding, we can represent the entire Live API as browsable Smalltalk classes. I always find this of huge benefit when doing mashups with external code libraries, but especially so with Live. The Live API is massive, and while the documentation is complete, it’s not very readable. It’s much more pleasant to learn about the API with the Smalltalk browsing tools. As usual, we can extend the API with composite methods of our own, aggregating multiple Live API calls into one. With this we can effectively extend the Live API with new features.
extending the Live API
One area of Live API extension where I’m working now is in song composition. Live has an Arrangement view, for a traditional recording studio workflow, and a Session view, for interactive performance. I find the “scenes” feature of the Session view very useful for sketching song sections, but Live’s support for playing them in different orders is minimal. With Caffeine objects representing scenes, I can compose larger structures from them, and play them however I like.
How would you extend the Live API? How would you simplify it?
The Node.JS server, JS proxying code, and the Max patcher that connects them are available as a self-contained M4L device, which can be applied to any Live track. Look for it in the devices folder of the Caffeine repository.
run headlessly in a web browser worker thread, NodeJS server worker thread, or NodeJS main thread.
We have all the components we need to connect teams of livecoders, sharing information from their IDEs as they work. What information would we like to share?
proactive conflict resolution
I’d like to share information that makes code integration easier, by spreading awareness of potential conflicts as soon as possible. Imagine, for example, that you’ve found a bug in a longstanding system method, and decide to start editing it. Before the commit of your change (which may still be days or weeks away), someone else on your team also happens to start editing that method. Wouldn’t it be nice to know that both of you are interested in changing the method?
If both of you are connected to a team network, your IDEs can notify each other when a potential conflict situation like this begins, and the two of you can resolve it through discussion. Such a feature could be vital in a team where responsibility for methods and classes is clearly and completely divided between authors.
The servers in this network can provide history services, too, acting as repositories of all the versions of methods and classes that have been committed by team members. This could aid in unit testing, sharing of works-in-progress, and deployment.
How would you use it?
How would you like to use such a system? How would your needs change when acting as a developer, or as a manager? I’m writing a specification now, and would love to hear your thoughts. Thanks!
Posted in Uncategorized on 18 January 2015 by Craig Latta
Hoi–
Well, this is perverse fun. :) The JavaScript WebSocket client API works from SqueakJS, so I guess I’ll write a WebSocket server to proxy peer-to-peer traffic between SqueakJS clients. This will let me implement the Flow external streaming “primitive” interface, using only the JavaScript bridge and no actual primitives. That will enable the Lightning remote messaging protocol, and then Naiad. I’ll run the server on try.squeak.org and any other site that wants to be a Lightning node.
Hi, Context 3 beta 5 is released. I’ve still got a bunch of changes pending, for a 3b6 release to follow shortly. This release is just to fix some startup problems on Windows, Linux, and Mac OS. You can also find the Spoon VM changes separated out, in the second “Resources” folder.
What I’d like is for you to just start the app and tell me the results, along with your host platform. Thanks!
