a most useful virtual machine debugging aid: simulated objects

Posted in Appsterdam, consulting, Context, Smalltalk, Spoon with tags , , , , , , on 2 December 2014 by Craig Latta

Squeak’s virtual machine simulator is extremely useful for debugging. You can use it to inspect and change objects “while time is stopped”, between the execution of individual virtual machine instructions. Traditionally, though, it takes an address-based view of objects. There are several useful utility methods which, given an object address, will print useful information to the Transcript. Wouldn’t it be nicer, though, if you could use normal inspectors to look through the fields of the objects in a simulated virtual machine’s object memory?

I created simulated objects for this purpose. They are instances of a SimulatedObject class; each one has an interpreter and an address. They can print useful information about themselves, like the interpreter can, but they can also modify themselves and interact with each other, changing the interpreter’s object memory appropriately. Are you wondering about the instructions of a compiled method? Would you like to make a few choice modifications to those instructions? A simulated object for that method’s address will help you.

Simulated objects play nicely with Squeak’s object inspectors, and, more importantly, with its object explorers. You feel like you’re inspecting normal objects, except that you can’t send normal messages to them. Or can you? I’m pondering this. It might be useful, for example, to terminate a process in a simulated interpreter’s object memory, without having to do it in another process. Time is stopped, but perhaps you could queue up messages to send when it starts again, through a collaboration between simulated objects and a coordinating object in the memory they describe.

I’ve been using simulated objects recently to chase references with the absolute assurance that I won’t be creating new ones. They’re very useful for debugging virtual machine primitives. Sometimes, when I’m debugging a headless system with a broken remote messaging system, it’s the only user interface I have for inspecting things. And it’s sure a lot nicer than inspecting things in a C debugger.

What will you do with them?

debugging remote exceptions works

Posted in consulting, Context, Smalltalk, Spoon with tags , , , , , , on 20 November 2014 by Craig Latta
a debugger for a remote unhandled exception

a debugger for a remote unhandled exception

I have debugging working for remote unhandled exceptions. My motivating use case was debugging messages not understood by the Context console’s embedded web server. The console is a headless app. In development, I run it with a remote-messaging connection to a headful system. Now, when there is an unhandled exception (like a message not understood), the exception requests that the headful system open a debugger (as its default action).

Before opening the debugger, the headful system replaces the sender of the first relevant context on the headless system with the last relevant context on the headful system, hiding all the remote-messaging-related contexts in between. The picture above shows an example of this. On the headful system, I sent “zork” to an object on the headless system. The debugger shows a continuous context stack which spans the two systems. This all works with little special handling in the debugger because of the complete transparency of remote messaging. It doesn’t matter that the contexts and methods that the debugger is manipulating happen to be remote.

Another VM debugging trick: halting

Posted in consulting, Smalltalk, Spoon with tags , , , , on 31 December 2013 by Craig Latta

Just another little VM debugging trick I use… In one of my VM plugins I include a little C function called “breakHere”, which Smalltalk can call as a primitive. I put a breakpoint on it in the C debugger, and then have a convenient way to break in the C debugger from Smalltalk.

VM debugging trick: browsing object memory snapshots made from the C debugger in the simulator

Posted in Smalltalk, Spoon with tags , , , , , , on 17 December 2013 by Craig Latta

Recently I made use of a virtual machine debugging trick that I don’t think I’ve written about here. The virtual machine simulator is a great way to browse around the state of object memory at the point of a VM crash, but it’s relatively slow (I measured it at about 3,000 instructions per second in my sonification work). The time it takes to get to that point might be prohibitively long.

Instead, you can run to that point in the C debugger (I use lldb on Mac OS), and make a snapshot by invoking primitiveSnapshot() manually. Then, open a simulator on that snapshot and browse the objects to your heart’s content. Depending on the error, you might even be able to modify the objects such that the active process may proceed, and you can snapshot a repaired object memory from the simulator.


toward a virtual machine browser

Posted in Naiad, Smalltalk, Spoon with tags , , on 27 November 2013 by Craig Latta

I just had an idea for the design of a “virtual machine browser”, for browsing the internal state of a running virtual machine simulator and the objects of the memory it’s running. Something more sophisticated than printing the debug support messages to the Transcript.
